DAFTAR ALAT PERAGA SMK KEJURUAN TEKNIK ELECTRIC
No. Nama Barang Spesifikasi QTY Satuan Harga Satuan Jumlah
1. Basic Electrical Trainer (1 PHASE) - 1 modul LTC-1-1 fuse box, sekring 2A, saklar putar, MCB 1 fasa 2A 1 Unit 18.600.000 18.600.000
- 1 modul LTC-1-2 KWH meter, standard PLN, 1 fasa 3 kawat
- 1modul LTC-1-3 Multirange timer 220 V/50 Hz
Timer ranges : 0,05 s to 300h
Mode : 6 timming modes
Output : 2 output NO/NC
1 Modul LTC-1-4 Push button NO/NC, max 5A, warna merah
1 Modul LTC-1-15 Push button NO/NC, max 5A, warna hijau
2 modul LTC-1-6 Series switch, max 5A
1 Modul LTC-1-7 Single switch, max 5A
1 Modul LTC-1-8 Cross switch, max 5A
2 Modul LTC-1-9 Change switch, max 5A
2 Modul LTC-1-10 Stop contact, inbow, 3 kawat
1 Modul LTC-1-11 Buzzer, 220 VAC
1 Modul LTC-1-12 Fitting lamp, 2 outbow
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs
1 kabel power, lampu pijar 40 Watt
Buku modul
2. Basic Electrical Trainer (3 PHASE) Modul LTC-1B-1 KWH meter 3 phase 1 Unit 25.200.000 25.200.000
Modul LTC-1B-2 MCB 3 phase
Modul LTC-1B-3 NFB 3 phase
Modul LTC-1B-4 Timer 220 V AC, 2NC, 2NO
Modul LTC-1B-5 2 Relay 220 VAC, 2NC, 2NO
Modul LTC-1B-6 Push button
Modul LTC-1B-7 Single switch
Modul LTC-1B-8 Series switch
Modul LTC-1B-9 Change switch
Modul LTC-1B-10 Cross Switch
Modul LTC-1B-11 Buzzer 220VAC
Modul LTC-1B-12 3 Fitting lamps for output
Modul LTC-1B-13 stop contact 1 phase
Modul LTC-1B-14 stop contact 3 phase
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs, 3 phase connector plug,
Buku modul
3. Fault and Control Installation Trainer 4 LTC-5-1 Contactor 220 VAC, max 25A, 5NO dan 2NC 1 Unit 30.200.000 30.200.000
4 LTC-5-2 Push botton NO/NC, max 5A, 2 merah dan 2 hijau
1 LTC-5-3 MCB 1 phase, max 6A
1 LTC-5-4 MCB 3 phase, max 10A
1 LTC-5-5 MCB 3 phase, max 6A
1 LTC-5-6 ELCB 3 fasa, 220VAC/30A, trip 0,03A
1 LTC-5-7 Timer 220VAC H3CR, Timer on/off delay, output 2 NO/NC
2 LTC-5-8 Thermo relay, 3 pole, max 16A, output 1NO/1NC
3 LTC-5-9 Indicator lamp 220V, merah, kuning, hijau
1 LTC-5-10 Emergency switch, max 5A
1 LTC-5-11 Selector switch max 5A
1 LTC-5-12 Power connector AC 3 phase 220V/380V, 4pole with ground
(P x L x T : 1100 x 800 x 1400 mm)
Kerangka besi Hollow dicat duco biru muda, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon.
Aksesoris :
Stackable plug with cage springs
3 phase connector plug
Buku modul
4. Motor Control Trainer 3 Modul LTC-3-1 Contactor 220 VAC, max 25A, 5NO/2NC 1 Unit 49.600.000 49.600.000
2 Modul LTC-3-2 Push button NO/NC, max 5A, 2 merah, 2 hijau
1 Modul LTC-3-3 Timer 220VAC H3CR, Timer On/Off delay, Output 2 NO/NC
1 Modul LTC-3-4 Indicator lamp 220 VAC, 1 merah, 1 kuning, 1 hijau
1 Modul LTC-3-5 MCB 3 fasa, max 10A, soket 3 fasa 4 pole
1 Modul LTC-3-6 Thermo relay, max 16A. Output 1NO/1NC
1 Modul LTC-3-7 Change over, max 5A
1 Modul LTC-3-8 Emergency Button, max 5A
1 Modul LTC-3-9 ELCB 3 fasa, max 40A
1 Modul LTC-3-10 MCB 1 fasa, max 6A
1 Modul LTC-3-11 MCB 3 fasa, max 6A
Aluminium profil Clas B, weight 0,891 kg x 3 btg
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs, 3 phase connector plug,
Buku modul
5. Inverter Trainer With Motor 1 LTC-9-1 Motor induksi 3 fasa 220/380 VAC 0,09 KW 1 Unit 29.600.000 29.600.000
1 LTC-9-2 Inverter 0,37 KW 1 phase to 3 phase 220 VAC
Input analog tegangan 0-10V:input analog arus 0-20mA: 5 input multifungsi
output relay ; output open colector
1 LTC-9-3 MCB 1fasa max 2A, jalur tenaga 1 fasa
1 LTC-9-4 MCB 3 fasa max 10A
5 LTC-9-5 Lampu indikator 220 VAC
1 LTC-9-6 Digital RPM meter
1 LTC-9-7 Proximity sensor 24VDC
1 LTC-9-8 Potensiometer 1K
1 LTC-9-9 Ampere meter max 5A
1 LTC-9-10 Ampere meter max 500mA
1 LTC-9-11 Volt meter AC max 300 V
1 LTC-9-12 Volt meter AC max 30 V
Instalation wiring CT 01 with 1,5 mm cable
(P x L x T : 800 x 400 x 600 mm)
Cover terbuat dari block board dicat biru muda, papan modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon.
Aksesoris :
1 set stackable plug with cage springs, buku modul/CD
6. Solar Cell Trainer 1 LTC-11-1 Solar cell modul 12 V/50W 1 Unit 22.400.000 22.400.000
1 LTC-11-2 Charger controller max 50V
1 LTC-11-3 Inverter DC 12V to AC 220V 100W, port input DC from Accumulator, port output AC 220V from inverter
1 LTC-11-4 Ampere meter max 5A
1 LTC-11-5 Voltmeter max 300V
1 LTC-11-6 DC lamp 12V 5W
1 LTC-11-7 AC lamp 220V 10W
2 LTC-11-8 Single switch, inbow
2 LTC-11-10 Stop contact, inbow
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
7. Sensor Trainer MTC-07-1 Magnet proximity NPN 2 Unit 12.200.000 24.400.000
MTC-07-2 Inductive Proximity NPN
MTC-07-3 Capacitive proximity NPN
MTC-07-4 Optical proximity no reflektor NPN
MTC-07-5 Optical proximity reflektor NPN
MTC-07-6 Optical proximity colour NPN
MTC-07-7 Power supply 24 VDC
(P x L x T : 400 x 300 x 150 mm)
Modul panel dan diagram terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunakan bahan PVC 4 mm cat standard biru muda.
Aksesoris :
1 set stackable plug with cage springs
1 kabel power, buku modul/CD
TOTAL 200.000.000
 |
| Add caption |
 |
| Add caption |
 |
| Add caption |
DAFTAR ALAT PERAGA SMK KEJURUAN TEKNIK ELECTRIC
No. Nama Barang Spesifikasi QTY Satuan Harga Satuan Jumlah
1. Basic Electrical Trainer (1 PHASE) - 1 modul LTC-1-1 fuse box, sekring 2A, saklar putar, MCB 1 fasa 2A 1 Unit 18.600.000 18.600.000
- 1 modul LTC-1-2 KWH meter, standard PLN, 1 fasa 3 kawat
- 1modul LTC-1-3 Multirange timer 220 V/50 Hz
Timer ranges : 0,05 s to 300h
Mode : 6 timming modes
Output : 2 output NO/NC
1 Modul LTC-1-4 Push button NO/NC, max 5A, warna merah
1 Modul LTC-1-15 Push button NO/NC, max 5A, warna hijau
2 modul LTC-1-6 Series switch, max 5A
1 Modul LTC-1-7 Single switch, max 5A
1 Modul LTC-1-8 Cross switch, max 5A
2 Modul LTC-1-9 Change switch, max 5A
2 Modul LTC-1-10 Stop contact, inbow, 3 kawat
1 Modul LTC-1-11 Buzzer, 220 VAC
1 Modul LTC-1-12 Fitting lamp, 2 outbow
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs
1 kabel power, lampu pijar 40 Watt
Buku modul
2. Basic Electrical Trainer (3 PHASE) Modul LTC-1B-1 KWH meter 3 phase 1 Unit 25.200.000 25.200.000
Modul LTC-1B-2 MCB 3 phase
Modul LTC-1B-3 NFB 3 phase
Modul LTC-1B-4 Timer 220 V AC, 2NC, 2NO
Modul LTC-1B-5 2 Relay 220 VAC, 2NC, 2NO
Modul LTC-1B-6 Push button
Modul LTC-1B-7 Single switch
Modul LTC-1B-8 Series switch
Modul LTC-1B-9 Change switch
Modul LTC-1B-10 Cross Switch
Modul LTC-1B-11 Buzzer 220VAC
Modul LTC-1B-12 3 Fitting lamps for output
Modul LTC-1B-13 stop contact 1 phase
Modul LTC-1B-14 stop contact 3 phase
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs, 3 phase connector plug,
Buku modul
3. Fault and Control Installation Trainer 4 LTC-5-1 Contactor 220 VAC, max 25A, 5NO dan 2NC 1 Unit 30.200.000 30.200.000
4 LTC-5-2 Push botton NO/NC, max 5A, 2 merah dan 2 hijau
1 LTC-5-3 MCB 1 phase, max 6A
1 LTC-5-4 MCB 3 phase, max 10A
1 LTC-5-5 MCB 3 phase, max 6A
1 LTC-5-6 ELCB 3 fasa, 220VAC/30A, trip 0,03A
1 LTC-5-7 Timer 220VAC H3CR, Timer on/off delay, output 2 NO/NC
2 LTC-5-8 Thermo relay, 3 pole, max 16A, output 1NO/1NC
3 LTC-5-9 Indicator lamp 220V, merah, kuning, hijau
1 LTC-5-10 Emergency switch, max 5A
1 LTC-5-11 Selector switch max 5A
1 LTC-5-12 Power connector AC 3 phase 220V/380V, 4pole with ground
(P x L x T : 1100 x 800 x 1400 mm)
Kerangka besi Hollow dicat duco biru muda, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon.
Aksesoris :
Stackable plug with cage springs
3 phase connector plug
Buku modul
4. Motor Control Trainer 3 Modul LTC-3-1 Contactor 220 VAC, max 25A, 5NO/2NC 1 Unit 49.600.000 49.600.000
2 Modul LTC-3-2 Push button NO/NC, max 5A, 2 merah, 2 hijau
1 Modul LTC-3-3 Timer 220VAC H3CR, Timer On/Off delay, Output 2 NO/NC
1 Modul LTC-3-4 Indicator lamp 220 VAC, 1 merah, 1 kuning, 1 hijau
1 Modul LTC-3-5 MCB 3 fasa, max 10A, soket 3 fasa 4 pole
1 Modul LTC-3-6 Thermo relay, max 16A. Output 1NO/1NC
1 Modul LTC-3-7 Change over, max 5A
1 Modul LTC-3-8 Emergency Button, max 5A
1 Modul LTC-3-9 ELCB 3 fasa, max 40A
1 Modul LTC-3-10 MCB 1 fasa, max 6A
1 Modul LTC-3-11 MCB 3 fasa, max 6A
Aluminium profil Clas B, weight 0,891 kg x 3 btg
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
Aksesoris :
Stackable plug with cage springs, 3 phase connector plug,
Buku modul
5. Inverter Trainer With Motor 1 LTC-9-1 Motor induksi 3 fasa 220/380 VAC 0,09 KW 1 Unit 29.600.000 29.600.000
1 LTC-9-2 Inverter 0,37 KW 1 phase to 3 phase 220 VAC
Input analog tegangan 0-10V:input analog arus 0-20mA: 5 input multifungsi
output relay ; output open colector
1 LTC-9-3 MCB 1fasa max 2A, jalur tenaga 1 fasa
1 LTC-9-4 MCB 3 fasa max 10A
5 LTC-9-5 Lampu indikator 220 VAC
1 LTC-9-6 Digital RPM meter
1 LTC-9-7 Proximity sensor 24VDC
1 LTC-9-8 Potensiometer 1K
1 LTC-9-9 Ampere meter max 5A
1 LTC-9-10 Ampere meter max 500mA
1 LTC-9-11 Volt meter AC max 300 V
1 LTC-9-12 Volt meter AC max 30 V
Instalation wiring CT 01 with 1,5 mm cable
(P x L x T : 800 x 400 x 600 mm)
Cover terbuat dari block board dicat biru muda, papan modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon.
Aksesoris :
1 set stackable plug with cage springs, buku modul/CD
6. Solar Cell Trainer 1 LTC-11-1 Solar cell modul 12 V/50W 1 Unit 22.400.000 22.400.000
1 LTC-11-2 Charger controller max 50V
1 LTC-11-3 Inverter DC 12V to AC 220V 100W, port input DC from Accumulator, port output AC 220V from inverter
1 LTC-11-4 Ampere meter max 5A
1 LTC-11-5 Voltmeter max 300V
1 LTC-11-6 DC lamp 12V 5W
1 LTC-11-7 AC lamp 220V 10W
2 LTC-11-8 Single switch, inbow
2 LTC-11-10 Stop contact, inbow
(P x L x T : 1000 x 400 x 760 mm)
Kerangka besi Hollow dicat duco biru muda, kerangka aluminium hollow class B sliding, modul terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunankan bahan PVC 2 mm cat standard biru muda.
7. Sensor Trainer MTC-07-1 Magnet proximity NPN 2 Unit 12.200.000 24.400.000
MTC-07-2 Inductive Proximity NPN
MTC-07-3 Capacitive proximity NPN
MTC-07-4 Optical proximity no reflektor NPN
MTC-07-5 Optical proximity reflektor NPN
MTC-07-6 Optical proximity colour NPN
MTC-07-7 Power supply 24 VDC
(P x L x T : 400 x 300 x 150 mm)
Modul panel dan diagram terbuat dari bahan pertinak 4 mm dicat putih, huruf dan gambar dicetak sablon dan box menggunakan bahan PVC 4 mm cat standard biru muda.
Aksesoris :
1 set stackable plug with cage springs
1 kabel power, buku modul/CD
TOTAL 200.000.000
Untuk pemesanan atau informasi silahkan hubungi alamat
kontak kami :
CV.ASAKA PRIMA | DUTA MEDIA GROUP.
PERCETAKAN & DISTRIBUTOR ALAT LAB & PERAGA
PENDIDIKAN.
Workshop : Jl.Kebon Besar No.22 BatuCeper - Tangerang -
Banten 15000.
Showroom & Marketing : Jl.Maulana Hasanudin No.52
Cipondoh - Tangerang 15000
Telp.021-55701397 – 021 55702265 /
Hp:0813.8053.7399./ 0877.7432.4146
